L198

产品参数

ModelL198
前框颜色/材质黑/塑膠
后壳颜色/材质黑/塑膠
底座颜色/材质黑/鐵
Size98
PanelIPS+DLED
Resolution3840 x 2160 (UHD)
Color1.07G (10bits)
Brightness cd/m2 (typ)500 cd/m2 ( typ. )
Contrast Ratio (typ)1300:1
Viewing Angle (min.)178°
Viewable Size (mm)2158.848(H) x 1214.352(V) mm
OSNA
CPUMST9U02V2
GPUDual Cortex-A72  over 2.0GHz
DDRN/A
Memory(eMMC)N/A
OSAndroid 7.1
CPURK3399
Quad Cortex-A53 64bit CPU
GPU
DDR4GB
Memory(eMMC)64GB
TouchNA
WiFi
OPS SlotYes
USB OTGYES
RTCYES
Power ManagementYES
Plug and PlayYES
USB Multi Media
Function
H.263: 1920*1080@60fps
H.265: 3840*2160P@60fps
H.264: 3840*2160P@30fps
VP8: 1920*1080@30fps
VP9: 3840*2160@60fps
MPEG1:1920*1080p@60fps
MPEG2:1920*1080p@60fps
MPEG4:1920*1080p@60fps
MJPEG:1920*1080@30fps
VC1:1920*1080p@60fps
Speaker10W x2 (78db, 200~20KHz)
VGANA
DVINA
Display port*3(in/out)
HDMI 2.0 In*3
HDMI1.4 InNA
HDMI 2.0 OutNA
RS232 In*1
RS232 Out*1
LAN*1
Extension IR*2(in/out)
SPDIF Out*1
USB 3.0*1
Type CNA
USB 2.0*1
SD Card*1
AUDIO InTBD
AUDIO OutTBD
Power SupplyAC 100 ~ 240V
Current Rating8A
Power Consumption(typ)520W
standby mode<0.5W
Operational Temperature0 ~ 40ºC
Operational Humidity20 – 80% (without condensation)
Storage Temperature-20~60 degC
Storage Humidity5- 95% (without condensation)
Net without stand (mm)2193.2×1248.2×83.8 mm
Net with stand (mm)NA
Net without stand (Kg)91.4 Kg
Net with stand (Kg)NA
Gross (Kg)134.5 Kg
Kensington Security LockN/A
VESA mounting interface800(H)x500(V)
Complied RegulatoryCCC
默认安装软件以及功能1、CMS
2、FileManager
3、Media Player
4、Browser     <浏览器>
5. PDF reader
线材2.0米HDMI线
1.5米电源线
摄像头选配
遥控器YES
无线传屏器NA
壁挂架NA
触控笔NA
蓝牙MICNA
底座NA
产品核心卖点1、高亮度IPS UHD硬屏。
2、按照国际标准设计、制造,兼容性好,稳定性强
3、支持标准OPS设备
