V343

产品参数

ModelV343
前框颜色/材质黑色/SGCC
后壳颜色/材质黑色/塑料
底座颜色/材质NA
Size43
PanelADS+DLED
Resolution1920 x 1080
Color8bit, 16.7 Million colors
Brightness cd/m2 (typ)360 nits
Contrast Ratio (typ)1200:1
Viewing Angle (min.)178°
Viewable Size (mm)940.896 (H)× 529.254(V)
OSAndroid 5.1
CPU海思Hi3751V551
双核A73-1.2GHz
GPU5核 mali-450
DDR1GB
Memory(eMMC)8GB
OSNA
CPUNA
GPUNA
DDRNA
Memory(eMMC)NA
TouchNA
WiFi2.4G IEE802.11 b/g/n 2T*2R
OPS SlotNA
USB OTGNA
RTCYES
Power ManagementYES
Plug and PlayYES
USB Multi Media
Function
AVS: 3840*2160P@60fps
H.265: 3840*2160P@60fps
VP9: 3840*2160P@60fps
H.264: 3840*2160P@30fps
MVC:1920*1080p@60fps
MPEG1:1920*1080p@60fps
MPEG2:1920*1080p@60fps MPEG4:1920*1080p@60fps
MPEG4 short header format (H.263 baseline):1920*1080p@60fps
DivX 3/4/5/6:1920*1080p@60fps AVS:1920*1080p@60fps
VC1:1920*1080p@60fps
VP6/8:1920*1080p@60fps
Speaker8W x2
VGA*1
DVINA
Display portNA
HDMI 2.0 InNA
HDMI1.4 In*2
HDMI 2.0 OutNA
RS232 In*1(RJ45接口界面)
RS232 OutNA
LAN*1(支持10/100兆网络)
Extension IRNA
SPDIF OutNA
USB 3.0*1
Type CNA
USB 2.0*1
SD CardNA
AUDIO InNA
AUDIO OutNA
Power Supply
Current RatingTBD
Power Consumption(typ)TBD
standby mode<0.5W
Operational Temperature5 – 40degC
Operational Humidity20 – 80% (without condensation)
Storage Temperature-20 – 60degC
Storage Humidity5 ~ 95% RH(非冷凝)
Net without stand (mm)968.2*562.8*79mm
Net with stand (mm)NA
Net without stand (Kg)8.73Kg
Net with stand (Kg)NA
Gross (Kg)11.7kg
Kensington Security LockYES
VESA mounting interface200mm*200mm
Complied RegulatoryCCC
默认安装软件以及功能1、CMS
2、SETTING
3、FileManager
4、云投屏
5、UPLAY
6、竖屏显示
7、DIY 开机LOGO和开机动画
8、可设定自动开关机时间
线材2.0米HDMI线
1.5米电源线
摄像头NA
遥控器YES
无线传屏器NA
壁挂架NA
触控笔NA
蓝牙MICNA
底座YES
